Australia's custom, scalable container houses feature prominently. As a two-bedroom prefabricated home with a bathroom, it cleverly uses container space to meet basic living needs. The modular design is easy to transport and assemble, and can flexibly expand the space according to the actual situation, whether in response to population growth or to adapt to different sites, providing comfortable, convenient and personalized living solutions.
40ft Expandable House Specifications | ||||
External dimensions (mm) | W6400*L11600*H2480(lower side 2270) | |||
Internal dimensions (mm) | W6280*L11200*H2280(lower side 2150) | |||
Folding (mm) | W2160*L11600*H2480 | |||
Total weight(kg) | 4800千克 | |||
Structure | Top side beam | t2.5mmQ235B | ||
Bottom side member | t2.5mmQ235B | |||
End side beam | t2.5mmQ235B | |||
Side wall frame | t2.5mmQ235B | |||
Subframe | t2.5mmQ235B | |||
Hanger | t4mmQ235B | |||
Folding hinge | 13mm Galvanized hinge | |||
Overall framework protective coating | Electrostatic spraying/straight white plastic powder | |||
The top and bottom of the middle cabinet | 80*100*2.5 thick tube | |||
The top and bottom of the side cabinet | 40*60*1.7 thick tube | |||
Top | External roof | 0.5mm galvanized sheet | ||
Indoor ceiling | t0.3mm 831ceiling board | |||
Board | Roof insulation layer | t50mm EPS composite board | ||
Side front and rear wall panels | t75mm EPS composite board | |||
Internal partition | t50mm EPS composite board | |||
Floor | Middle floor | glass magnesium board or cement fiber board | ||
Side floor | Bamboo flooring | |||
Electric | Electrical wiring must be installed strictly in accordance with moisture-proof regulations, and all electrical products must comply with CE certification. Connect the circuit according to the electrical engineering specifications. Indoor: 3 LED lights, 3 five hole single opening sockets, 3 ten hole sockets, 3 air conditioning sockets, and 1 20A leakage protector. | |||
Voltage 220V, 50Hz | ||||
Door | Aluminum alloy glass door | |||
Window | Aluminum windows | |||
Warranty | One year warranty |
